The Digital Controller For Multiscroll Chillers ESIE06-05

2–16 Part 2 – Functional Description

Screen 2 This screen shows the actual operational information about the control mode, the inlet, outlet water

temperature and ambient temperature.

Remark: For a DICN system, the INLET WATER and OUTLET WATER values are the values of the

individual unit, not of the system. Temperatures of the system can be consulted in the first screen of

the network menu.

These screens show the actual operational information about the EEV control. They are only visible

when they are enabled in the Service/EEV menu.

Screen 3

Display Description

COOL operation in cooling mode

HEAT operation in heating mode

INLSP(1)(2) inlet temperature setpoint 1 (or 2 in case of dual set-

point setting)

OUTSP(1)(2) outlet temperature setpoint 1 (or 2 in case of dual set-

point setting)

INLET WATER Actual inlet water temperature

OUTLET WATER Actual outlet water temperature

AMBIENT Actual ambient temperature

_ COOL. INLSP1:012.0 °C

INLET WATER:013.6 °C

OUTLET WATER:007.0 °C

AMBIENT:006.5 °C

C1 TEMP.READOUT

SUCTION C1:007.4 °C

SUPERHEAT C1:007.3 °C

EEV PULS C1:0000PLS
