ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–41
3
2
4
5
1
2.8.11 Defrost
Manual Defrost This screen allows activation of a manual defrost.
Settings:
_vc
013.6 °C
∞11
∞21
012.0 °C∞12
∞22
≤0U4
H
H
…
UNIT/CIR1/CIR2
DEFROST
: OFF: No manual defrost is requested
ON : manual defrost is requested and busy
Unit defrost : Both circuits will execute a defrost cycle, due to one circuit
defrost control, the 2nd circuit defrost will only start after the
defrost finish of the 1st circuit.
Circuit defrost : Only this circuit will execute a defrost cycle.
Remark: If manual defrost is chosen (for 1 circuit/2 circuits)
■ If condition of
defrost is satisfied
start defrost
AND
indicate ON for manual defrost
■ If condition of
defrost is not
satisfied
return to OFF indication and ignore manual defrost order
MANUAL DEFROST_v
UNIT DEFROST:OFF
CIR1 DEFROST:OFF
CIR2 DEFROST:OFF
