General Outline ESIE06-05
1–26 Part 1 – System Outline
3
11
4
5
1.18 Electrical Specifications for options: EWYQ080-100DAYN
Electrical
specifications
The table below contains the electrical specifications for the options of the EWYQ080-100DAYN.
Electrical specifications options
OPSP
Units EWYQ080DAYN* EWYQ100DAYN*
Std Pump Starting method Direct On-Line
Power kW 2,2 2,2
Maximum Running current A 4,45 4,45
Starting current A 42 42
OPHP
Units EWYQ080DAYN* EWYQ100DAYN*
High Esp Pump Starting method Direct On-Line
Power kW 5,5 5,5
Maximum Running current A 11,2 11,2
Starting current A 131 131
OP10
Units EWYQ080DAYN* EWYQ100DAYN*
Heater Tape Supply Voltage V 230+/-10%
Recommended fuses A 2 x 10 A
Power standard model 1 x 300W 1 x 300W
Power model with pump 2 x 300W 2 x 300W
Power model with pump and OPBT 2 x 300W + 1 x 150W 2 x 300W + 1 x 150W
