ESIE06-05 General Outline
Part 1 – System Outline 1–33
3
1
4
5
1.24 Optional equipment for EWYQ-DAYN (N-P-B)
Optional equipment for EWYQ-DAYNN
Capacity: 080-250 kW
Notes
EWYQ080DAYNN EWYQ150DAYNN EWYQ230DAYNN
EWYQ100DAYNN EWYQ180DAYNN EWYQ250DAYNN
EWYQ130DAYNN EWYQ210DAYNN
Option number Option description Unit size Availability
080 100 130 150 180 210 230 250
Standard unit ° ° ° ° ° ° ° °
OPSC Single pump contactor ° ° ° ° ° ° ° ° fact. mount.
OPTC Twin pump contactor ° ° ° ° ° ° ° ° fact. mount.
OPSP Single pump ° ° ° ° ° ° ° ° fact. mount.
OPTP Twin pump (1 pump house, dual motor) ° ° ° ° ° ° ° ° fact. mount.
OPHP High ESP pump (single pump only) ° ° ° ° ° ° ° ° fact. mount.
OPBT Buffer tank ° ° ° ° ° ° ° ° fact. mount.
OPIF Inverter fans (For low ambient -15°C) ° ° ° ° ° ° ° ° fact. mount.
OPZL Glycol 0°C / -10°C ° ° ° ° ° ° ° ° fact. mount.
OP03 Dual pressure relief valve ° ° ° ° ° ° ° ° fact. mount.
OP10 Evaporator heater tape ° ° ° ° ° ° ° ° fact. mount.
OP12 Option valves (discharge-, liquid line- and suction stop valve) °(S) °(S) °(S) °(S) °(S) °(S) °(S) °(S) fact. mount.
OP57 A-meter / V-meter ° ° ° ° ° ° ° ° fact. mount.
OPLN Low noise = OPIF + Compressor housing ° ° ° ° ° ° ° ° fact. mount.
OPCG Condenser protection grills ° ° ° ° ° ° ° ° fact. mount.
Available kits
EKLONPG Gateway for LON ° ° ° ° ° ° ° ° Kit
EKBNPG Gateway for BACNET ° ° ° ° ° ° ° ° Kit
EKACPG Address card ° ° ° ° ° ° ° ° Kit
EKRUPG Remote user interface ° ° ° ° ° ° ° ° Kit
° Available
- Not available
(S) Option required for Swedish national law SNFS 1992:16
