The Digital Controller For Multiscroll Chillers ESIE06-05
2–24 Part 2 – Functional Description
3
1
2
4
5
These screens show the actual operational information about the total running hours in cooling and
heating mode and the number of compressor stops of each circuit, as well as the total running hours
of the pumps.
Screen 18 & 19
These screens are only visible if the unit has 2 circuits.
Screen 20 & 21
EXTRA READOUT
C11RH:00000hCS:00000
C11C:00000h H:00000h
_
RHP1:00001hP2:00000h
EXTRA READOUT
C21RH:00000hCS:00000
C21C:00000h H:00000h
_
CIRCUIT 1/ COMPRESSOR 1 CIRCUIT 1/ COMPRESSOR 2
Display Description
CxxRH: CS RH: Total running hours of this circuit
CS: Total compressor starts of this circuit
CxxC: H C: Running hours in cooling mode
H: Running hours in heating mode
RHP1: 2 RHP1: Running hours of pump 1
P2: Running hours of pump 2
EXTRA READOUT
C12RH:00000hCS:00000
C12C:00000h H:00000h
_
EXTRA READOUT
C22RH:00000hCS:00000
C22C:00000h H:00000h
_
CIRCUIT 2/ COMPRESSOR 2
CIRCUIT 2/ COMPRESSOR 1
