ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–45
3
2
4
5
1
2.10 Info menu
Introduction Using this menu, the additional information about the unit can be consulted.
Time info This screen shows the actual time and date.
Unit info This screen shows the unit type.
Display Description
TIME Actual time
DATE Actual day and date
_v
TIME: 22h05
DATE: WED 24/01/07
TIME INFO
Display Description
UNITTYPE: XX-XX-XX The first two letters tell that the unit is air cooled, the following two give
the type of unit and the number indicates the capacity power of the unit.
C: Indicates the type of the compressor.
SCL : scroll
CIRC: EVAP: COILC: Indicates the quantity of circuits, the evaporators and whether 1 or 2
coils are present per circuit.
EEV Indicates the type of electronic expansion valve.
P : PCASO EEV
REFRIGERANT: XXXX Refrigerant type : R410 a
_
UNIT:AW-RH-250 C:SCL
CIR:2 EVAP:1 COILC:2
EEV:P REF:R410A
UNIT INFO
