ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–85
3
2
4
5
1
2.15.7 Communication
Communication
PCB Information
This screen shows additional information about the extension PCB, communication PCB and
communication P1 P2 PCB.
EEV PCB
Information
This screen shows additional information about the EEV PCB.
Display Description
EXT. PCB
Extension PCB with 4 solid state relays and hybrid type (PCB with Ana-
logue outputs)
COMM. PCB Communication PCB with DIII and serial communication
COMM. P1 P2 PCB None (not used)
_v
EXT. PCB:4SSR+HIC
COMM. PCB:DIII+SER
COMM.P1P2 PCB:NONE
COMMUNICATION
Display Description
EEV. PCB UNI POLAR, PCB type used for EEV control.
_
EEV. PCB:UNI POLAR
COMMUNICATION PCB
