The Digital Controller For Multiscroll Chillers ESIE06-05
2–58 Part 2 – Functional Description
3
1
2
4
5
2.13 Network Menu
The network menu is only accessible when MS OPTION is set to “YES” in the SERVICE/DICN menu.
Network This screen shows the temperatures of the network (DICN) system.
Network Overview This screen shows the status and capacity of all the units in the DICN network.
Display Description
COOL Cooling operation is selected.
HEAT Heating operation is selected.
INLSP1/ INLSP2 Gives the setpoint you selected to use (dual setpoint if selected)
INLSP1 : inlet water setpoint 1
INLSP2 : inlet water setpoint 2 (dual setpoint)
INLET WATER Inlet temperature of the inlet water on the master unit
_v
COOL. INLSP1:012.0 °C
INLET WATER:013.6 °C
NETWORK
_^M:NORMAL
SL1:NORMAL
SL3:NORMAL
SL2:NORMAL
CAP:000%
CAP:000%
CAP:000%
CAP:000%
