ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–51
3
2
4
5
1
Compressor
Outputs
This screen shows the status of the compressor outputs.
Fan Inputs/Outputs This screen shows the status of the relay outputs of the fans from circuit 1.
Remark: When the unit has standard ON/OFF fans, 3 fan steps are present. When the unit has
inverter and ON/OFF fans, only fan steps 1 or 1 and 3 are present (depending on unit size).
Display Description
C11 Compressor 1 status of circuit 1
C12 Compressor 2 status of circuit 1
C21 Compressor 1 status of circuit 2
C22 Compressor 2 status of circuit 2
_
C11:ON C12:ON
C21:ON C22:ON
COMP. OUTPUTS
Display Description
C1 FANSTEP 1 Indicates the status of the fan contactor of circuit 1
C1 FANSTEP 2 Indicates the status of the fan contactor of circuit 1
C1 FANSTEP 3 Indicates the status of the fan contactor of circuit 1
_
C1 FANSTEP 1:CLOSED
C1 FANSTEP 2:CLOSED
C1 FANSTEP 3:CLOSED
FAN INP/OUTPUTS
