ESIE06-05 General Outline
Part 1 – System Outline 1–15
3
1
4
5
1.8 Technical specifications for options: EWYQ080-100DAYN
Technical
specifications
The table below contains the technical specifications for the options of the EWYQ080-100DAYN.
Technical specifications options
OPSP
Units EWYQ080DAYN* EWYQ100DAYN*
Weight Additional machine weight kg 250 250
Additional operation weight kg 268 268
Additional gross weight kg 250 250
Pump Type
Single-stage-in-line-pumps Single-stage-in-line-pumps
Quantity 1 1
Model TP50-240/2 TP50-240/2
Nominal Static Height Unit cooling kPa 173 154
Hydraulic components Additional unit water volume l 18 18
Expansion vessel l 35
Pre-charge pressure exp. vessel bar 1,5
Safety valve bar 3
OPSP + OPBT
Units EWYQ080DAYN* EWYQ100DAYN*
Weight Additional machine weight kg 300 300
Additional operation weight kg 508 508
Additional gross weight kg 300 300
Pump Type
Single-stage-in-line-pumps Single-stage-in-line-pumps
Quantity 1 1
Model TP50-240/2 TP50-240/2
Nominal Static Height Unit cooling kPa 173 154
Hydraulic components Buffer tank l 190 190
Additional unit water volume l 208 208
Expansion vessel l 35
Pre-charge pressure exp. vessel bar 1,5
Safety valve bar 3
OPHP
Units EWYQ080DAYN* EWYQ100DAYN*
Pump Type
Single-stage-in-line-pumps Single-stage-in-line-pumps
Quantity 1 1
Model TP50-430/2 TP50-430/2
Nominal Static Height Unit Cooling kPa 365 348
