General Outline ESIE06-05
1–20 Part 1 – System Outline
3
11
4
5
1.13 Electrical Specifications for options: EWAQ080-100DAYN
Electrical
specifications
The table below contains the electrical specifications for the options of the EWAQ080-100 DAYN.
Electrical specifications options
OPSP
Units EWAQ080DAYN* EWAQ100DAYN*
Std Pump Starting method Direct On-Line
Power W 2,2kW 2,2kW
Maximum Running current A 4,5 4,5
Starting current A 42 42
OPHP
Units EWAQ080DAYN* EWAQ100DAYN*
High Esp Pump Starting method Direct On-Line
Power W 5,5kW 5,5kW
Maximum Running current A 11,2 11,2
Starting current A 131 131
OP 10
Units EWAQ080DAYN* EWQ100DAYN*
Heater Tape Supply Voltage V 230+/-10%
Recommended fuses A 2x 10 A
Power standard model 1 x 300W 1 x 300W
Power model with pump 2 x 300W 2 x 300W
Power model with pump and buffer
tank
2 x 300W + 1 x 150W 2 x 300W + 1 x 150W
