The Digital Controller For Multiscroll Chillers ESIE06-05
2–52 Part 2 – Functional Description
3
1
2
4
5
Fan Input/Outputs This screen shows the status of the relay outputs of the fans from circuit 2.
Remark: When the unit has standard ON/OFF fans, 3 fan steps are present. When the unit has
inverter and ON/OFF fans, only fan steps 1 or 1 and 3 are present (depending on unit size).
Changeable Digital
Inputs
This screen shows the status of the digital inputs.
Display Description
C2 FANSTEP 1 Indicates the status of the fan contactor of circuit 2
C2 FANSTEP 2 Indicates the status of the fan contactor of circuit 2
C2 FANSTEP 3 Indicates the status of the fan contactor of circuit 2
_
C2 FANSTEP 1:CLOSED
C2 FANSTEP 2:CLOSED
C2 FANSTEP 3:CLOSED
FAN INP/OUTPUTS
Display Description
DI1 Changeable digital input 1 + status of input
DI2 Changeable digital input 2 + status of input
DI3 Changeable digital input 3 + status of input
_ CHANG.
DI1 NONE
DI2 NONE
DI3 NONE
DIG. INPUTS
