ESIE06-05 The Digital Controller For Multiscroll Chillers

Part 2 – Functional Description 2–11

How to switch

between screens

Each menu contains a number of screens. You can switch between the screens, using the h or g

keys. In the upper-left corner of the screen you will find a screen indicator, indicating whether there is

a previous or next screen.

An overview is given in the table below:

Screen Detail Each screen contains 4 lines which give information about a setting (a description and an entry field).

The entry fields can be adjusted using the

h and the g keys.

The cursor is marked by the sign "_". The cursor can be moved between the screen indicator and the

entry fields using the

q key.

The cursor can be moved directly to the screen indicator by pressing the

f key.

Remark: Make sure that the cursor is at the screen indicator position when scrolling through the

screens. After changing a entry field push the

q key to confirm the setting.

The screen indicator Indicates that you should do the following

First screen of the menu, press

h to go to the next screen

Last screen of the menu, press

g to go to the previous

screen

either return to the previous or go to the next screen

_/ l i n e 1:

T I T L E

l i n e 2 v a l u e 1 :

1 0

l i n e 3 v a l u e 2 :

2 0

l i n e 4 v a l u e 3 :

3 0

Cursor

Screen indicator

Information Entry field
