Wiring Layout ESIE06-05
1–92 Part 1 – System Outline
3
11
4
5
F11B, F12B autofuse for compressors (M11C, M12C,) (Not for EWA/YQ80-100)
F14B, F24B autofuse for fan motors circuit 1, circuit 2
F15B, F25B ** autofuse for fan motors circuit 1, circuit 2 (OPIF)
F16B ** autofuse for pump (K1P) (Only for OPSP/ OPHP/ OPSC/ OPTP/OPTC)
F17B ** autofuse for pump (K2P) (only for OPTP/OPTC)
F21B, F22B autofuse for compressors (M21C, M22C)
H1-6P * indication lamp for changeable digital outputs
H11P, H12P * indication lamp for operation compressor circuit 1 (M11C, M12C)
H21p, H22P * indication lamp for operation compressor circuit 2 (M21C, M22C)
HAP-HEP (A*P) light emitting diode PCB
K1A, K2A auxiliary relay for compressor safety circuit 1, circuit 2
K1P ## pump contactor (only for OPSP/ OPHP/OPSC/OPTP/OPTC)
K1S * overcurrent relay pump
K1R-K22R (A*P) PCB relay
K2P ** pump contactor (only for OPTP/ OPTC)
K3A auxiliary relay for heater tape
K11M, K12M compressor contactor for circuit 1
K13F, K14F fan contactor for circuit 1
K13S, K14S fan overcurrent relay for circuit 1
K15F fan contactor for circuit 1
(Only for EWAQ80-100/180-210/240-260)
(Only for EWYQ80-100/180-210/230-250)
K15S fan overcurrent relay for circuit 1
(Only for EWAQ80-100/180-210/240-260)
(Only for EWYQ80-100/180-210/230-250)
K16F fan contactor for circuit 1
(Only for EWAQ80-100/240-260)
(Only for EWYQ80-100/230-250)
K16S fan overcurrent relay for circuit 1
(Only for EWAQ80-100/240-260)
(Only for EWYQ80-100/230-250)
K21M, K22M compressor contactor for circuit 2
K23F, K24F fan contactor for circuit 2
K23S, K24S fan overcurrent relay for circuit 2
K25F fan contactor for circuit 2
(Only for EWAQ180-210/240-260)
(Only for EWYQ180-210/230-250)
Part number Description
