ESIE06-05 Wiring Layout
Part 1 – System Outline 1–127
3
1
4
5
Communication PCB (A02P)
HCP, HDP, HEP LED (service monitor green)
S3A dipswitch (terminal resistor)
EEV PCB (A71P)
X86A Y11E Electronic expansion valve
X87A Y21E Electronic expansion valve
HAP LED (service monitor green)
DS1 dipswitch (address)
EEV PCB (A72P) (Only EWYQ)
X86A Y12E Electronic expansion valve (only EWYQ)
X87A Y22E Electronic expansion valve (only EWYQ)
HAP LED (service monitor green)
DS1 dipswitch (address)
Main PCB (A21P)
X12A (1-3-5) DI: Reverse phase detection (L1-L2-L3) c2
X4A DI: High pressure switch c2
X5A DI: Compressor interclock 1 c2
X6A DI: Compressor interlock 2 c2
X7A DI: Fan overcurrent relay Fanstep 1 c2
X8A DI: Fan overcurrent relay Fanstep 2 c2
X9A DI: Fan overcurrent relay Fanstep 3 c2
X27A not used
X13A DO: Compressor contactor 1 c2
X14A DO:Compressor contactor 2 c2
X17A DO: Reverse valve c2 (Only for EWYQ)
X19A (1-3) DO: Fanstep 1 c2
X19A (5-7) DO: Fanstep 2 c2
X20A DO: Fanstep 3 c2
X34A AI: Heating suction temperature sensor 1 c2 (Only for EWYQ)
X35A AI: Heating suction temperature sensor 2 c2 (Only for EWYQ)
