ESIE06-05 General Outline
Part 1 – System Outline 1–55
3
1
4
5
Components The table below lists the components.
No. Component No. Component
1 Evaporator 17 Switchbox
2 Condensor 18 Digital display controller (Inside switchbox)
3 Compressor 19 Field wiring intake
4 Expansion valve + sight glass 20 Main isolator switch
5 Discharge stopvalve (Optional) 21 Transport beam
6 Suction stopvalve (Optional) 22 Flowswitch
7 Liquid stopvalve (Optional) 23 Fan
8 Chilled water IN (Victaulic coupling) 24 Safety valve
9 Chilled water OUT (Victaulic coupling) 25 High pressure sensor
10 Water drain evaporator 26 Low pressure sensor
11 Air purge 27 High pressure switch
12 Leaving water temperature sensor 28 Oil sight glass
13 Entering water temperature sensor 29 Water filter
14 Ambient temperature sensor 30 Frame
15 Drier + charge valve 31 4-way valve
16 Power supply intake 32 Liquid receiver
