ESIE06-05 Piping Layout
Part 1 – System Outline 1–71
3
1
4
5
M11-12C
Compressor motors circuit 1
R34T
Suction temperature sensor circuit 2
M13-15F
Fan motors circuit 1
R37T
Refrigerant piping temperature sensor circuit 2
R14T
Suction temperature sensor circuit 1
S2PH
High pressure switch circuit 2
R17T
Refrigerant piping temperature sensor circuit 1
R35T
Discharge temperature sensor circuit 2
S1PH
High pressure switch circuit 1
B2PH
High pressure sensor circuit 2
R15T, R25T
Discharge temperature sensor circuit 1
B2PL
Low pressure sensor circuit 2
B1PH
High pressure sensor circuit 1
Y21E
Electronic expansion valve cooling circuit 2
B1PL
Low pressure sensor circuit 1
R1T
Ambient temperature sensor
Y11E
Electronic expansion valve cooling circuit 1
R2T
Evaporator inlet water temperature sensor
M21-22C
Compressor motors circuit 2
R3T
Evaporator outlet water temperature sensor
M23-25F
Fan motors circuit 2
: Check valve : Flange connection
: Flare connection : Pinched pipe
: Screw connection : Spinned pipe
