ESIE06-05 Piping Layout
Part 1 – System Outline 1–81
3
1
4
5
.
M11-12C
Compressor motors circuit 1
R34T
Suction temperature sensor circuit 2
M13-16F
Fan motors circuit 1
R36T, R46T
Coil temperature sensor circuit 2
R14T
Suction temperature sensor circuit 1
R37T
Refrigerant piping temperature sensor circuit 2
R16T, R26T
Coil temperature sensor circuit 1
S2PH
High pressure switch circuit 2
R17T
Refrigerant piping temperature sensor cir-
cuit 1
Y2R
Reverse valve circuit 2
S1PH
High pressure switch circuit 1
R35T, R45T
Discharge temperature sensor circuit 2
Y1R
Reverse valve circuit 1
B2PH
High pressure sensor circuit 2
R15T, R25T
Discharge temperature sensor circuit 1
B2PL
Low pressure sensor circuit 2
B1PH
High pressure sensor circuit 1
Y21E
Electronic expansion valve cooling circuit 2
B1PL
Low pressure sensor circuit 1
R38T, R48T
Heating suction temperature sensor circuit 2
Y11E
Electronic expansion valve cooling circuit 1
Y22E, Y23E
Electronic expansion valve heating circuit 2
R18T, R28T
Heating suction temperature sensor circuit
1
R1T
Ambient temperature sensor
Y12E, Y13E
Electronic expansion valve heating circuit 1
R2T
Evaporator inlet water temperature sensor
M21-22C
Compressor motors circuit 2
R3T
Evaporator outlet water temperature sensor
M23-26F
Fan motors circuit 2
: Check valve : Flange connection
: Flare connection : Pinched pipe
: Screw connection : Spinned pipe
