GRAPHITE 58G026 [14/116] Preparation for operation
![GRAPHITE 58G026 [14/116] Preparation for operation](/views2/2041623/page14/bge.png)
14
7. Be careful, sharp edges!
8. Use protective gloves
9. Recycling.
10. Protection class 2.
11. Segregated waste collection.
12. Do not throw cells into re.
13. Hazardous to water environment.
14. Do not allow to heat above 50°C.
CONSTRUCTION AND USE
Angle grinder is a hand held, battery powered tool. Drive consists of a DC brushless
motor, whose rotational speed is transferred with angle gear transmission. It
can be used for grinding and cutting. This type of power tool is widely used for
removal of burrs from metal surfaces, weld surface treatment, cutting tubes and
other metal objects etc. With the right equipment the angle grinder can be used
not only for cutting or grinding, but also removal of rust, paint coats etc.
Range of use covers all areas of repairs and construction in internal furnishing,
adaptation of premises etc.
The device is designed for dry operation only and cannot be used
for polishing. Use the power tool in accordance with the manufacturer’s
instructions only.
Inappropriate use.
• Do not process materials that contain asbestos. Asbestos is a carcinogen.
• Do not process materials that produce ammable or explosive dust.
During operation power tool produces sparks that can ignite produced fumes.
• Do not grind with wheels designed for cutting. Cutting wheels work
with front edge surface and grinding with side surface of the wheel can cause
damage, and in consequence personal injuries of the operator.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing
pages of this manual.
1. Spindle lock button
2. Switch
3. Main handle
4. Additional handle
5. Wheel guard
6. Outer ange
7. Inner ange
8. Lever (wheel guard)
9. Battery
10. Battery lock button
11. LED diodes
12. Charger
13. Button for battery level indication
14. Battery level indicator (LED)
* Dierences may appear between the product and drawing.
MEANING OF SYMBOLS
WARNING
EQUIPMENT AND ACCESSORIES
1. Wheel guard - 1 pce
2. Special key - 1 pce
3. Additional handle - 1 pce
PREPARATION FOR OPERATION
REMOVING AND INSERTING THE BATTERY
• Push the battery lock button (10) and slide out the battery (9) (g. A).
• Insert charged battery (9) into the handle holder, you should hear when the
battery lock button (10) snaps.
BATTERY CHARGING
The device is supplied with partially charged battery. The battery should
be charged in ambient temperature between 4°C and 40°C. New battery,
or one that has not been used for a long time, will reach full eciency after
approximately 3 to 5 charge/discharge cycles.
• Remove the battery (9) from the device (g. A).
• Connect the charger to mains socket (230 V AC).
• Slide the battery (9) into the charger (12) (g. B). Ensure the battery is
properly tted (pushed to the end).
When the charger is connected to a mains socket (230 V AC), the green diode
(11) on the charger turns on to indicate connected supply.
When the battery (9) is placed in the charger (12), the red diode (11) on the
charger turns on to indicate that the charging is in progress.
Simultaneously, green diodes (14) of the battery level indication are ashing
in dierent congurations, see description below.
• All diodes are ashing - battery is empty and requires charging.
• 2 diodes are ashing - the battery is partially discharged.
• 1 diode is ashing - the battery level is high.
Once the battery is charged, the diode (11) on the charger lights green, and
all battery level diodes (14) light continuously. After some time (approx. 15 s)
battery level indication diodes (14) turn o.
Do not charge the battery for more than 8 hours. Exceeding this
time limit may cause damage to battery cells. The charger will not turn
o automatically when the battery is full. Green diode on the charger
will remain on. Battery level indication diodes turn o after some time.
Disconnect power supply before removing the battery from the charger
socket. Avoid consecutive short chargings. Do not charge the battery
after short use of the tool. Signicant decrease of the period between
chargings indicates the battery is worn out up and should be replaced.
Batteries heat up when charging. Do not operate just after charging –
wait for the battery to cool down to room temperature. It will prevent
battery damage.
BATTERY LEVEL INDICATION
The battery is equipped with signalisation of the battery level (3 LED diodes)
(14). To check battery level status, press the button for battery level indication
(13) (g. C). When all diodes are lit, the battery level is high. When 2 diodes are
on, the battery is partially discharged. When only one diode is lit, the battery is
discharged and must be recharged.
INSTALLATION AND ADJUSTMENT OF THE WHEEL GUARD
Wheel guard protects the operator from splinters, accidental contact
with the working tool or sparks. It should be installed at all times. Make
sure that protective section faces the operator.
The wheel guard design allows for setting the guard tool free in an optimal
position.
• Loosen and pull away the lever (8) on the wheel guard (5).
• Turn the wheel guard (5) to desired position.
• Lower the lever (8) to lock.
Deinstallation and setting of the wheel cover are similar to installation, only
the sequence of actions is reversed.
REPLACEMENT OF WORKING TOOLS
Wear work gloves during working tool replacement.
Spindle lock button (1) is used only to lock the grinder spindle
for installation or removal of working tool. It cannot be used as a brake
button when the wheel is rotating. Otherwise the grinder may be
damaged or the user may be injured.
WHEEL INSTALLATION
For grinding and cutting wheels below 3 mm thickness, screw the outer
ange (6) nut onto the at surface on the wheel side (g. D).
• Press the spindle lock button (1).
• Insert the special key (included) into holes of the outer ange (6) (g. E).
• Turn the key to loosen and remove the outer ange (6).
• Install wheel, make sure it is pressed against the inner ange surface (7).
• Screw the outer ange (6) on, slightly tighten with the special key.
You can remove the wheel by following the installation procedure in reverse
sequence. During installation, the wheel should be pressed against surface of
the inner ange (7) and centred when seated on its neck.
INSTALLATION OF WORKING TOOLS WITH THREADED HOLE
• Press the spindle lock button (1).
• Remove previously installed working tool, if any.
• Remove two anges before installation: inner ange (7) and outer ange (6).
• Screw threaded part of the working tool onto the spindle, then slightly
tighten.
Remove working tools with threaded hole by following installation procedure
in reversed order.
INSTALLATION OF THE ANGLE GRINDER ON AN ANGLE GRINDER SUPPORT
It is possible to use the angle grinder in special support for angle grinders.
