7. УПРАВЛЕНИЕ ПОДСИСТЕМОЙ SYSLOG
7.1. clear logging
Данная команда производит очистку локального журнала устройства.
Синтаксис
clear logging
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p15
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# clear logging
7.2. description
Данная команда задает описание для текущего удаленного сервера журналирования.
Команда выполняется в режиме настройки сервера журналирования.
Использование отрицательной формы команды удаляет описание сервера.
Синтаксис
description STRING
no description
Параметры
• STRING — описание удаленного сервера журналирования (строка). Максимальная
длина строки - 32 символа, при наличии в описании символов пробела следует
заключать всю строку в кавычки.
Необходимый уровень привилегий
p10
Командный режим
config-logging-host
Пример
82
