![Eltex ME5200 [312/670] Max ibgp ecmp paths](/views2/1569351/page312/bg138.png)
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-vrf-address-family-ipv4-unicast
config-router-bgp-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# max-ebgp-ecmp-paths 2
0/ME5100:example_router01(config-unicast)#
13.51. max-ibgp-ecmp-paths
Команда аналогична команде bgp max-ibgp-ecmp-paths, только для заданного address-family.
Отрицательная форма команды возвращает значение по умолчанию, 0. При этом
используется значение, заданное командой bgp max-ibgp-ecmp-paths из router bgp.
Синтаксис
max-ibgp-ecmp-paths INTEGER
no max-ibgp-ecmp-paths
Параметры
• INTEGER — количество ECMP-маршрутов. Диапазон допустимых значений: 0..8.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-vrf-address-family-ipv4-unicast
config-router-bgp-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# max-ibgp-ecmp-paths 2
0/ME5100:example_router01(config-unicast)#
13.52. max-peers
Команда ограничивает количество динамических соседей в заданном listen-range
Отрицательная форма команды возвращает значение по умолчанию (0), что снимает
ограничение.
