Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peergroup
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peergroup
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# enforce-first-as disable
0/ME5100:example_router01(config-neighbor)# no enforce-first-as disable
13.41. fully-specified
Команда позволяет перераспределять local-маршруты с максимально возможной для
данного Address Family длиной префикса.
Отрицательная форма команды возвращает поведение по умолчанию, перераспределяются
все local-маршруты.
Синтаксис
[no] fully-specified
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast-redistribution-local
config-router-bgp-address-family-ipv6-unicast-redistribution-local
config-router-bgp-vrf-address-family-ipv4-unicast-redistribution-local
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-local
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# redistribution local Redist-Local
0/ME5100:example_router01(config-local)# fully-specified
0/ME5100:example_router01(config-local)# no fully-specified
0/ME5100:example_router01(config-local)#
283
