Eltex ME5200 [170/670] Lfa protection disable
![Eltex ME5200 [170/670] Lfa protection disable](/views2/1569351/page170/bgaa.png)
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2
config-router-ospfv2-vrf
config-router-ospfv3
config-router-ospfv3-vrf
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# lfa include-all
0/ME5100:example_router01(config-filter)#
11.30. lfa protection disable
Данная команда отключает LFA-защиту маршрутов, построенных через указанный
интерфейс.
Отрицательная форма команды разрешает LFA-защиту маршрутов, построенных через
данный интерфейс.
Синтаксис
[no] lfa protection disable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area-interface
config-router-ospfv2-vrf-area-interface
config-router-ospfv3-area-interface
config-router-ospfv3-vrf-area-interface
Пример
149
