11.5. area-aggregate
Данная команда позволяет создать в конфигурации правило для суммарного маршрута с
LSA Type 3 или LSA Type 7.
Отрицательная форма команды удаляет данное правило из конфигурации.
Синтаксис
[no] area-aggregate { nssa-external-lsa | summary-lsa } IPv4_PREFIX_FORMAT
Параметры
• IPv4_PREFIX_FORMAT — значение префикса в формате IPv4-подсети
• nssa-external-lsa — LSA NSSA external link (Type 7 LSA)
• summary-lsa — OSPF summary LSA (Type 3 LSA)
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area
config-router-ospfv2-vrf-area
config-router-ospfv3-area
config-router-ospfv3-vrf-area
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# area-aggregate summary-lsa 10.0.0.0/8
0/ME5100:example_router01(config-area-aggregate)#
11.6. area-id
Команда задает номер области (Area ID) для маршрута, анонсируемого командой host.
Отрицательная форма команды удаляет настройку.
Синтаксис
area-id AREA
no area-id
Параметры
• AREA — значение OSPF area в формате IPv4-адреса.
Необходимый уровень привилегий
p10
132
