Eltex ME5200 [561/670] Preempt delay
![Eltex ME5200 [561/670] Preempt delay](/views2/1569351/page561/bg231.png)
маршрутизаторов группы. При отсутствии данной настройки, маршрутизатор станет
Мастером тогда и только тогда, когда в течение 3х timers advertise не примет ни одного
VRRP-Announcement от соседних маршрутизаторов.
Синтаксис
[no] preempt
Необходимый уровень привилегий
p10
Командный режим
config-router-vrrp-interface
Пример
0/ME5100:example_router01(config)# router vrrp interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# preempt
0/ME5100:example_router01(config-tengigabitethernet)#
25.7. preempt delay
Настройка, позволяющая задать длительность паузы принятия мастерства.
Отрицательная форма команды возвращает значение по умолчанию (0).
Синтаксис
[no] preempt delay SECONDS
Параметры
• SECONDS — время задержки в секундах (0-3600).
Необходимый уровень привилегий
p10
Командный режим
config-router-vrrp-interface
Пример
0/ME5100:example_router01(config)# router vrrp interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# preempt delay 60
0/ME5100:example_router01(config-tengigabitethernet)#
25.8. source-ip
Команда, позволяющая указать IP адрес источника служебных VRRP-Announcement в случае
наличия нескольких подсетей на интерфейсе.
540
