Eltex ME5200 [462/670] Router pim
![Eltex ME5200 [462/670] Router pim](/views2/1569351/page462/bg1ce.png)
Отрицательная форма команды устанавливает значение по умолчанию (asm).
Синтаксис
pim-mode { asm | ssm }
no pim-mode
Параметры
• asm — any-source multicast, он же классический PIM SM;
• ssm — source-specific multicast.
Необходимый уровень привилегий
p10
Командный режим
config-router-pim-address-family-static-rp
Пример
0/ME5100:example_router01(config)# router pim address-family ipv4 static-rp
232.10.0.0/16
0/ME5100:example_router01(config-static-rp)# pim-mode ssm
0/ME5100:example_router01(config-static-rp)#
18.9. router pim
Включение протокола PIM на устройстве.
Отрицательная форма команды отключает протокол PIM на устройстве и удаляет все
связанные настройки.
Синтаксис
[no] router pim
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# router pim
0/ME5100:example_router01(config)#
441
