0/ME5100:example_router01(config)# ip-community TestCommList
0/ME5100:example_router01(config-ip-community)# seq-num 10
0/ME5100:example_router01(config-seq-num)# type standard
0/ME5100:example_router01(config-standard)# community 65535:666
0/ME5100:example_router01(config-standard)# community 65535:777
0/ME5100:example_router01(config-standard)#
13.102.3. ge
Команда задает минимальную длину префикса.
Отрицательная форма команды удаляет значение.
Синтаксис
ge INTEGER
no ge
Параметры
• INTERGER — длина префикса в битах (0..128)
Необходимый уровень привилегий
p10
Командный режим
config-prefix-list-seq-num
Пример
0/ME5100:example_router01(config)# prefix-list Test
0/ME5100:example_router01(config-prefix-list)# seq-num 10
0/ME5100:example_router01(config-seq-num)# ge 8
0/ME5100:example_router01(config-seq-num)#
13.102.4. ip-community
Команда создает именованный список BGP community и входит в режим его
конфигурирования.
Отрицательная форма команды удаляет список.
Синтаксис
[no] ip-community COMMLIST
Параметры
• COMMLIST — имя списка ip-community (1..32)
Необходимый уровень привилегий
p10
338
