0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# ipv4-dscp 1-4,30,34
0/ME5100:example_router01(config-ipv4-dscp)#
23.9. ipv6-dscp
Команда позволяет классифицировать IPv6 трафик по полю DSCP в заголовке пакета и
входит в режим конфигурирования параметров данного трафика.
Отрицательная форма команды удаляет настройку.
Синтаксис
[no] ipv6-dscp DSCP
Параметры
• DSCP — десятичное значение DSCP (0..63). Могут быть использованы списки и
диапазоны, разделенные запятой: 1-4,30,34.
Необходимый уровень привилегий
p10
Командный режим
config-qos-rewrite-map
config-qos-tc-map
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# rewrite-map 1
0/ME5100:example_router01(config-rewrite-map)# ipv6-dscp 0,8,16,20-26
0/ME5100:example_router01(config-ipv4-dscp)#
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# ipv6-dscp 56
0/ME5100:example_router01(config-ipv4-dscp)#
23.10. match tc
Команда задает соответствие трафика, имеющего внутреннюю классификацию (Traffic
Class), указанному классу (Class Map). Для внутренней классификации используется Traffic
Class Map.
Отрицательная форма команды удаляет соответствие.
499
