Пример
0/ME5100:example_router01(config)# line telnet session-timeout 600
5.18. method
Данная команда создает метод аутентификации внутри соответствующего списка
аутентификации.
Отрицательная форма команды удаляет соответствующий метод из списка
аутентификации.
Синтаксис
[no] method { local | tacacs | radius }
Параметры
• local — метод устанавливает локальную аутентификацию, то есть аутентификацию
согласно настройкам 'enable' и 'user' в текущей конфигурации;
• tacacs — метод устанавливает аутентификацию через сконфигурированные TACACS+-
серверы;
• radius — метод устанавливает аутентификацию через сконфигурированные RADIUS-
серверы.
Необходимый уровень привилегий
p15
Командный режим
config-aaa-authentication-enable
config-aaa-authentication-login
Пример
0/ME5100:example_router01(config)# aaa authentication login LOGIN-LIST
0/ME5100:example_router01(config-login)# method tacacs
0/ME5100:example_router01(config-login)# method local
5.19. password
При использовании в разделе настройки TACACS+ и RADIUS-серверов (config-aaa-radius-
server-vrf-host-ipv4, config-aaa-radius-server-host-ipv4, config-aaa-tacacs-server-vrf-host-ipv4)
данная команда задает ключ, который будет использован при обращении к
соответствующему серверу.
При использовании в разделе настройки локальных пользователей (config-user) команда
задает пароль для локального пользователя.
60
