Eltex ME5200 [222/670] Graceful restart disable
![Eltex ME5200 [222/670] Graceful restart disable](/views2/1569351/page222/bgde.png)
Синтаксис
[no] graceful-restart auto-reset
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# graceful-restart auto-reset
0/ME5100:example_router01(config-isis)#
12.17. graceful-restart disable
Данная команда отключает поддержку протокола IS-IS Graceful Restart (GR).
Отрицательная форма команды включает поддержку данного протокола.
Синтаксис
[no] graceful-restart disable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# graceful-restart disable
0/ME5100:example_router01(config-isis)#
12.18. graceful-restart help-peer disable
Данная команда позволяет выключить поддержку IS-IS Graceful Restart (GR) Helper на
201
