Eltex ME5200 [202/670] Show ospfv2 neighbors
![Eltex ME5100 [202/670] Show ospfv2 neighbors](/views2/1569351/page202/bgca.png)
p2
Командный режим
GLOBAL
Пример
….жно попытаться сгенерировать LSA Type 2
0/ME5100:example_router01# show ospfv2 interfaces link-state
Wed Aug 2 12:18:50 2017
Ê Routing Process: test, with ID 22.22.22.22
Ê Router is an area border router
ÊInterface Loopback 1, state: loopback, status: up Area 0.0.0.1
Ê Interface Loopback 2, state: down, status: down Area 0.0.0.0
Ê Interface Tengigabitethernet 0/0/10, state: down, status: down Area 0.0.0.0
11.71. show ospfv2 neighbors
Данная команда отображает информацию по OSPFv2 соседям.
Синтаксис
show ospfv2 [vrf { all | VRF_NAME }] neighbors [detailed | virtual interfaces]
Параметры
• VRF_NAME — имя Virtual Routing and Forwarding сущности;
• detailed — параметр для вывода детальной информации по OSPFv2 interfaces;
• virtual interfaces — параметр для вывода информации по OSPFv2 соседствам,
построенным через virtual-if.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
181
