Eltex ME5200 [501/670] Lldp optional tlv disable
![Eltex ME5200 [501/670] Lldp optional tlv disable](/views2/1569351/page501/bg1f5.png)
форма команды устанавливает значение по умолчанию (30).
Синтаксис
lldp notification-interval SECS
no lldp interval
• SECS — интервал отправки уведомлений, от 5 до 3600 в секундах.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# lldp notification-interval 120
21.15. lldp optional-tlv disable
Данная команда определяет, какие опциональные TLV-поля (Type, Length, Value) не будут
включены устройством в передаваемый LLDP-пакет. По умолчанию передаются следующие
параметры: mgmt-addr, port-desc, system-cap, system-desc, system-name. Отрицательная форма
команды включает указанный параметр. Команда применяется ко всем интерфейсам, на
которых включен протокол, и не заданы опциональные TLV-поля.
Синтаксис
[no] optional-tlv { mgmt-addr | port-desc | system-cap | system-desc | system-name }
disable
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# optional-tlv system-cap disable
21.16. lldp pps
Данная команда задает максимальное количество LLDP-пакетов в секунду, принимаемых от
соседнего устройства. Отрицательная форма команды устанавливает значение по
умолчанию (5).
Синтаксис
480
