8.24. show interfaces utilization
Данная команда выводит в табличном виде информацию по текущим загрузке физических
и агрегированных интерфейсов.
Синтаксис
show interfaces utilization
Параметры
Команда не содержит параметров.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show interfaces utilization
Tue Oct 3 06:02:44 2017
Ê Interface IF index Period, s Sent, Kbit/s Recv, Kbit/s Frames sent, pps
Frames recv, pps
Ê ---------------- --------- ---------- ------------- ------------- -----------------
-----------------
Ê te 0/0/1 25 300 0 0 0
0
Ê te 0/0/2 12 300 0 0 0
0
Ê te 0/0/3 26 300 0 0 0
0
Ê te 0/0/4 27 300 0 0 0
0
Ê te 0/0/5 28 300 0 0 0
0
Ê te 0/0/6 14 300 0 4 0
6
Ê te 0/0/7 29 30 0 0 0
0
Ê te 0/0/8 30 30 0 0 0
0
Ê te 0/0/9 3 300 0 0 0
0
Ê te 0/0/10 9 300 0 0 0
0
Ê te 0/0/11 31 300 0 0 0
0
Ê te 0/0/12 2 300 10 10 10
10
Ê te 0/0/13 16 300 0 0 0
113
