![Eltex ME5200 [252/670] Retransmit interval](/views2/1569351/page252/bgfc.png)
• STRING — имя правила для редистрибуции.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-address-family-ipv4-unicast
config-router-isis-address-family-ipv6-unicast
config-router-isis-vrf-address-family-ipv4-unicast
config-router-isis-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# redistribution bgp RULE
0/ME5100:example_router01(config-bgp)#
12.62. retransmit-interval
Данная команда устанавливает интервал для пересылок Link-state Packet (LSP).
Отрицательная форма команды устанавливает значение по умолчанию (10).
Синтаксис
retransmit-interval SECONDS
no retransmit-interval
Параметры
• SECONDS — интервал между пересылками одной и той же LSP в секундах.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-interface-level
config-router-isis-vrf-interface-level
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/8.10
0/ME5100:example_router01(config-tengigabitethernet-sub)# level level-2
0/ME5100:example_router01(config-level)# retransmit-interval 15
0/ME5100:example_router01(config-level)#
231
