Отрицательная форма команды удаляет route-map.
Синтаксис
[no] route-map NAME
Параметры
• NAME — имя route-map (1..32)
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)#
13.102.20. seq-num
Команда создает нумерованное правило в экземпляре route-map, ip-community или prefix-
list, и входит в режим его конфигурирования.
Отрицательная форма команды удаляет правило.
Синтаксис
[no] seq-num SEQNUM
Параметры
• SEQNUM — номер правила (1..4294967295)
Необходимый уровень привилегий
p10
Командный режим
config-ip-community
config-ip-extcommunity
config-multicast-address-list
config-multicast-group-list
config-prefix-list
config-route-map
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq-num 10
0/ME5100:example_router01(config-seq-num)#
347
