0/ME5100:example_router01# show candidate-config
Tue May 16 18:37:32 2017
aaa authentication login AAA-TAC
Ê method tacacs
Ê method local
exit
backup to tftp://192.168.16.245/me5100/
Ê interval 1440
Ê on-commit
Ê vrf mgmt-intf
exit
clock timezone gmt 7
...
0/ME5100:example_router01# show candidate-config router isis
Tue May 16 18:48:24 2017
router isis 1
Ê is-level level-2
Ê net 49.0002.0000.0000.0101.00
Ê host-name er01
Ê interface tengigabitethernet 0/0/3
Ê point-to-point
Ê exit
Ê interface tengigabitethernet 0/0/1.4001
Ê point-to-point
Ê exit
Ê interface bundle-ether 1.12
Ê exit
Ê interface loopback 1
Ê passive
Ê exit
exit
3.17. show configuration changes
Данная команда выводит изменения в кандидат-конфигурации относительно текущей
активной конфигурации устройства — то есть изменения, которые были внесены в сессиях
конфигурирования, но еще не применены.
Синтаксис
show configuration changes
40
