![Eltex ME5000 [483/670] Version](/views2/1569351/page483/bg1e3.png)
Командный режим
config-router-igmp-interface-static-group
Пример
0/ME5100:example_router01# configure
0/ME5100:example_router01(config)# router igmp interface tengigabitethernet 0/0/4
0/ME5100:example_router01(config-tengigabitethernet)# static-group 233.1.1.1
0/ME5100:example_router01(config-static-group)# static-source 10.0.0.1
0/ME5100:example_router01(config-static-group)#
19.17. version
Команда задает версию IGMP протокола на указанном интерфейсе. Значение версии
используется при отправке сообщений IGMP General Query на интерфейсе.
Отрицательная форма команды устанавливает значение по умолчанию (3).
Синтаксис
version VERSION
no version
Параметры
• VERSION — версия IGMP-протокола, допустимые значения: 1..3.
Необходимый уровень привилегий
p10
Командный режим
config-router-igmp-interface
Пример
0/ME5100:example_router01# configure
0/ME5100:example_router01(config)# router igmp interface tengigabitethernet 0/0/4
0/ME5100:example_router01(config-tengigabitethernet)# version 2
0/ME5100:example_router01(config-tengigabitethernet)#
462
