Eltex ME5200 [488/670] Mesh group
![Eltex ME5000 [488/670] Mesh group](/views2/1569351/page488/bg1e8.png)
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp
config-router-msdp-vrf
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# keepalive 3
0/ME5200:example_router01(config-msdp)#
20.8. mesh-group
Команда позволяет группировать MSDP сессии, задавая Mesh Group. Участники одной Mesh
группы имеют полную связность друг с другом. SA-сообщения, принятые от соседа внутри
группы, не передаются другим соседям.
Отрицательная форма команды удаляет настройку.
Синтаксис
mesh-group MESH_GROUP
no mesh-group
Параметры
• MESH_GROUP — строковое имя mesh группы (1..31)
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp-peer
config-router-msdp-vrf-peer
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# peer 10.0.0.1
0/ME5200:example_router01(config-peer)# mesh-group Group1
0/ME5200:example_router01(config-peer)#
20.9. originator-ip
Команда задает IP-адрес RP в SA-сообщениях протокола MSDP.
Отрицательная форма команды удаляет настройку.
467
