![Eltex ME5200 [518/670] Class map](/views2/1569351/page518/bg206.png)
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# policy-map POLICY-MAP-01
0/ME5100:example_router01(config-policy-map)# class class-default
0/ME5100:example_router01(config-class)#
23.6. class-map
Команда создает классификатор (Class Map) с заданным именем и переходит в режим его
конфигурирования.
Отрицательная форма команды удаляет классификатор.
Синтаксис
[no] class-map CLASS_MAP
Параметры
• CLASS_MAP — имя классификатора. Допустимая длина: 1..63.
Необходимый уровень привилегий
p10
Командный режим
config-qos
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# class-map CLASS-MAP-01
0/ME5100:example_router01(config-class-map)#
23.7. dscp-both
Команда задает пакеты с каким значением DSCP попадут в правило модификации (rewrite-
map) или классификации (tc-map). Сравнение DCSP производится как для IPv4, так и для IPv6
пакетов.
Отрицательная форма команды удаляет настройку
Синтаксис
dscp-both DSCP_DEC
no dscp-both
Параметры
• DSCP_DEC — десятичное значение DSCP (0..63). Возможно использование списков
(разделение запятой) и диапазонов (через дефис).
497
