![Eltex ME5200 [336/670] Set origin](/views2/1569351/page336/bg150.png)
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-connected
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-isis
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-local
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-ospf
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-static
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# redistribution connected Redist-Connected
0/ME5100:example_router01(config-connected)# set med 150
0/ME5100:example_router01(config-connected)# no set med
0/ME5100:example_router01(config-connected)#
13.82. set origin
Команда задает атрибут origin code для маршрутов, перераспределенных в указанном
правиле редистрибуции.
Отрицательная форма команды возвращает поведение по умолчанию, origin code для
редистрибцуции задается как incomplete.
Синтаксис
set origin { egp | igp | incomplete }
no set origin
Параметры
• egp — Eterior Gateway Protocol
• igp — Interior Gatewai Protocol
• incomplete — Incomplete (default)
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast-redistribution-connected
config-router-bgp-address-family-ipv4-unicast-redistribution-isis
config-router-bgp-address-family-ipv4-unicast-redistribution-local
config-router-bgp-address-family-ipv4-unicast-redistribution-ospf
config-router-bgp-address-family-ipv4-unicast-redistribution-static
config-router-bgp-address-family-ipv6-unicast-redistribution-connected
config-router-bgp-address-family-ipv6-unicast-redistribution-isis
config-router-bgp-address-family-ipv6-unicast-redistribution-local
config-router-bgp-address-family-ipv6-unicast-redistribution-ospf
config-router-bgp-address-family-ipv6-unicast-redistribution-static
config-router-bgp-vrf-address-family-ipv4-unicast-redistribution-connected
315
