11.68. show ospfv2 fast-reroute
Данная команда отображает информацию, связанную с OSPF IP LFA FRR.
Синтаксис
show ospfv2 fast-reoute [ ipv4 { IPv4_FORMAT }| ipv6 { IPv6_FORMAT } | summary]
Параметры
• IPv4_FORMAT — значение искомого префикса в формате IPv4-адреса.
• summary — суммарный вывод по протоколу OSPF IP LFA FRR.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
