Командный режим
config-router-ospfv2-area-interface
config-router-ospfv2-host
config-router-ospfv2-vrf-area-interface
config-router-ospfv2-vrf-host
config-router-ospfv3-area-interface
config-router-ospfv3-host
config-router-ospfv3-vrf-area-interface
config-router-ospfv3-vrf-host
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# metric 10
0/ME5100:example_router01(config-tengigabitethernet)#
11.38. metric-conversion
Данная команда позволяет производить математические операции между метрикой
протокола, из которого происходит редистрибуция, и значением метрики для данного
правила редистрибуции metric-value.
Отрицательная форма команды возвращает значение по умолчанию (constant).
Синтаксис
metric-conversion { constant | inverse | same | scale-down | scale-up | truncate }
no metric-conversion
Параметры
• constant — используется значение метрики в конфигурации правила редистрибуции;
• inverse — используется абсолютная разница между значением метрики исходного
протокола маршрутизации и значения метрики в конфигурации правила
редистрибуции;
• same — используется значение метрики исходного протокола маршрутизации;
• scale-down — используется значение метрики исходного протокола маршрутизации,
деленное на значение метрики в конфигурации правила редистрибуции;
• scale-up — используется значение метрики исходного протокола маршрутизации,
умноженное на значение метрики в конфигурации правила редистрибуции;
• truncate — используется меньшее из значений исходного протокола маршрутизации
и значения метрики в конфигурации правила редистрибуции.
Необходимый уровень привилегий
p10
