Синтаксис
address-family {ipv4 | ipv6} destination {IPv4_FORMAT | IPv6_FORMAT}
no address-family {ipv4 | ipv6} destination
Параметры
• IPv4 (A.B.C.D) — Задать адрес получателя.
• IPv6 (X:X:X:X::X) — Задать адрес получателя.
Необходимый уровень привилегий
p10
Командный режим
config-bfd-session
Пример
0/ME5100:example_router01(config)# bfd session test
0/ME5100:example_router01(config-session)# address-family ipv4 local 11.11.11.11
0/ME5100:example_router01(config-session)#
17.3. address-family local
Данная команда позволяет задать IPv4/IPv6-адрес источника.
Отрицательная форма команды удаляет из конфигурации IPv4/IPv6-адрес источника BFD
сессии.
Синтаксис
address-family {ipv4 | ipv6} local {IPv4_FORMAT | IPv6_FORMAT}
no address-family {ipv4 | ipv6} local
Параметры
• IPv4 (A.B.C.D) — Задать адрес источника.
• IPv6 (X:X:X:X::X) — Задать адрес источника.
Необходимый уровень привилегий
p10
Командный режим
config-bfd-session
Пример
0/ME5100:example_router01(config)# bfd session test
0/ME5100:example_router01(config-session)# address-family ipv4 destination 12.12.12.12
0/ME5100:example_router01(config-session)#
431
