Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# vlan-pcp-inner 7
0/ME5100:example_router01(config-vlan-pcp-inner)# exit
0/ME5100:example_router01(config-tc-map)# no vlan-pcp-inner 7
0/ME5100:example_router01(config-tc-map)#
23.38. vlan-pcp-outer
Команда позволяет классифицировать трафик по полю Priority Code Point внешнего 802.1q
VLAN tag и входит в режим конфигурирования параметров данного трафика. В режиме
конфигурирования rewrite-map команда позволяет определить, пакеты с каким PCP будут
модифицированы.
Отрицательная форма команды удаляет настройку.
Синтаксис
[no] vlan-pcp-outer PCP
Параметры
• PCP — десятичное значение Priority Code Point. Диапазон допустимых значений: 0..7.
Необходимый уровень привилегий
p10
Командный режим
config-qos-rewrite-map
config-qos-tc-map
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# vlan-pcp-outer 7
0/ME5100:example_router01(config-vlan-pcp-outer)# exit
0/ME5100:example_router01(config-tc-map)# no vlan-pcp-outer 7
0/ME5100:example_router01(config-tc-map)#
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# rewrite-map 1
0/ME5100:example_router01(config-rewrite-map)# vlan-pcp-outer 1
0/ME5100:example_router01(config-vlan-pcp-outer)#
517
