Синтаксис
[no] redistribution isis STRING
Параметры
• STRING — имя правила редистрибуции. Допустимая длина: 1..128.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-vrf-address-family-ipv4-unicast
config-router-bgp-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# redistribution isis Redist-IS-IS
0/ME5100:example_router01(config-isis)#
13.68. redistribution local
Команда создает правило перераспределения local маршрутов в BGP RIB указанного Address
Family и входит в режим конфигурации дополнительных параметров.
Отрицательная форма команды удаляет указанное правило.
Синтаксис
[no] redistribution local STRING
Параметры
• STRING — имя правила редистрибуции. Допустимая длина: 1..128.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-vrf-address-family-ipv4-unicast
config-router-bgp-vrf-address-family-ipv6-unicast
Пример
303
