Командный режим
config-mpls-ldp-discovery-interface
config-mpls-ldp-neighbor
Пример
0/ME5100:example_router01(config)# mpls
0/ME5100:example_router01(config-mpls)# ldp
0/ME5100:example_router01(config-ldp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# holdtime-interval 60
0/ME5100:example_router01(config-neighbor)#
14.11. ldp
Команда включает протокол LDP и входит в режим его конфигурирования
Отрицательная форма команды отключает протокол и удаляет всю связанную
конфигурацию
Синтаксис
[no] ldp
Параметры
Команда не содержит аргументов
Необходимый уровень привилегий
p10
Командный режим
config-mpls
Пример
0/ME5100:example_router01(config)# mpls
0/ME5100:example_router01(config-mpls)# ldp
0/ME5100:example_router01(config-ldp)#
14.12. mpls forwarding interface
Команда включает MPLS на заданном интерфейсеи входит в режим конфигурации
дополнительных параметров.
Отрицательная форма команды выключает MPLS на интерфейсе и удаляет всю связанную
конфигурацию.
372
