![Eltex ME5200 [422/670] Multicast rate](/views2/1569351/page422/bg1a6.png)
Командный режим
config-l2vpn-bridge-domain
config-l2vpn-xconnect-group-p2p
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# mtu 9000
0/ME5100:example_router01(config-bridge-domain)#
15.24. multicast rate
Команда задает ограничение в килобитах в секунду для multicast-трафика в бридж-домене.
Параметр burst позволяет задать размер допустимых вспышек трафика.
Отрицательная форма команды удаляет настройку
Синтаксис
multicast rate RATE [ burst KBITS ] no multicast rate
Параметры
• RATE — битрейт в kbps (64..300000000)
• KBITS — допустимый размер вспышек в kbits (0..33292)
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain-interface-storm-control
config-l2vpn-bridge-domain-storm-control
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain Test
0/ME5100:example_router01(config-bridge-domain)# storm-control
0/ME5100:example_router01(config-storm-control)# multicast rate 1024 burst 64
0/ME5100:example_router01(config-storm-control)#
15.25. name
Команда задает необязательное имя псевдопровода.
Отрицательная форма команды удаляет настройку.
Синтаксис
name NAME
no name
