Синтаксис
spf threshold updates-restart NUMBER
[no] spf threshold updates-restart
Параметры
• NUMBER — количество обновлений LSDB, которые вызывают её перезапуск
(0..4294967295), default: 4294967295.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# spf threshold updates-restart 15
0/ME5100:example_router01(config-isis)#
IMPORTANT
Данная команда перезаписывает значение таймера, описанного в spf
interval maximum-wait.
12.79. spf threshold updates-start
Данная команда создает в конфигурации правило для определения количества пакетов,
необходимых для запуска алгоритма Shortest Path First (SPF).
Отрицательная форма команды удаляет данное правило из конфигурации.
Синтаксис
spf threshold updates-start NUMBER
[no] spf threshold updates-start
Параметры
• NUMBER — количество обновлений LSDB, которые вызывают её перезапуск
(0..4294967295), default: 4294967295.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
Пример
253
