11.46. nssa default-information-originate metric
Команда задает метрику маршрута по умолчанию для NSSA зоны.
Отрицательная форма команды возвращает значение по умолчанию (1).
Синтаксис
nssa default-information-originate metric METRIC
no nssa default-information-originate metric
Параметры
• METRIC — числовое значение метрики (0-2147483647)
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area
config-router-ospfv2-vrf-area
config-router-ospfv3-area
config-router-ospfv3-vrf-area
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.1
0/ME5100:example_router01(config-area)# nssa default-information-originate metric 10
0/ME5100:example_router01(config-area)# no nssa default-information-originate metric
0/ME5100:example_router01(config-area)#
11.47. nssa default-information-originate metric-type
Команда задает тип метрики маршрута по умолчанию для NSSA зоны.
Отрицательная форма команды возвращает значение по умолчанию (standard).
Синтаксис
nssa default-information-originate metric-type { external-type-1 | external-type-2 |
standard }
no nssa default-information-originate metric-type
Параметры
• external-type-1 — External OSPF type 1 метрика;
• external-type-2 — External OSPF type 2 метрика;
• standard — стандартная OSPF метрика.
Необходимый уровень привилегий
161
