Пример
0/ME5100:example_router01(config)# lacp system mac-address 00:00:11:22:33:44
0/ME5100:example_router01(config)#
24.10. lacp system priority
Установка системного приоритета для задания в LACPDU.
Отрицательная форма команды устанавливает значение по умолчанию (32768).
Синтаксис
lacp system priority (1-65535)
no lacp system priority
Параметры
• (1-65535) — системный приоритет LACP.
Необходимый уровень привилегий
p10
Командный режим
configure
Пример
0/ME5100:example_router01(config)# lacp system priority 1
0/ME5100:example_router01(config)#
24.11. load-balance
Настройка способа балансировки в bundle-интерфейсе.
Отрицательная форма команды убирает балансировку в данной группе агрегации.
Синтаксис
load-balance { hash | round-robin }
no load-balance
Параметры
Команда не содержит параметров.
Необходимый уровень привилегий
p10
Командный режим
config-lacp-interface
523
